52mm (2-1/16") Wideband AFR + Boost Gauge — White OLED Display, Bosch LSU 4.9 (10:1-20:1 / -30 to +45 PSI)

Two of the most critical forced induction readings -- air/fuel ratio and boost pressure -- in a single 52mm gauge. The white OLED digital display in the center shows live AFR, while the bar graph LED ring around the outside tracks boost pressure in real time. One gauge hole. Two data streams.

Powered by a genuine Bosch LSU 4.9 5-wire heated wideband O2 sensor, this gauge measures AFR across a full 10.0:1 to 20.0:1 range with the accuracy that tuners rely on. The 0-5 volt analog output connects directly to data loggers and standalone ECUs.

Specs

*        Gauge diameter: 52mm (2-1/16")

*        AFR range: 10.0:1 to 20.0:1

*        Boost range: -30 in. Hg vacuum to +45 PSI

*        O2 sensor: Bosch LSU 4.9, 5-wire heated wideband

*        AFR display: White OLED digital readout (center)

*        Boost display: Bar graph LED ring (outer)

*        Output: 0-5V analog signal for data logging / ECU integration

*        Optional: dims 20% with headlights on (switch wire included)

What's in the box

*        Wideband AFR + Boost gauge

*        Bosch LSU 4.9 5-wire heated wideband O2 sensor

*        Waterproof boost sensor

*        Silicone boost tubing

*        Weld-in bung

*        10-foot plug-and-play wiring harness (gauge to O2 sensor)

*        Visor/hood

*        Decals

*        Installation instructions

The complete all-in-one gauge for turbocharged and supercharged builds. Fits any 52mm A-pillar pod. Add the matching pod for your vehicle in our pod catalog and complete the setup in one order.
